Overview
AIM Industries offers a robust and efficient PET Bottle Baling Machine in Mali for recycling units, waste-management companies, beverage industries, scrap dealers and municipal collection centres.
Our machine compresses loose PET bottles into compact bales, helping businesses save valuable storage space, reduce transportation expenses and improve material handling.
Available in 25 MT, 40 MT, 60 MT and 80 MT models, the machine can meet different production requirements.
Its sturdy construction, powerful hydraulic system and convenient operating options ensure reliable performance under demanding industrial conditions.
How Does a PET Bottle Baling Machine Work?
The PET Bottle Baling Machine follows a simple and efficient compression process:
- Operators place loose PET bottles inside the machine through the feed opening.
- The hydraulic system moves the compression platen with high pressure.
- The machine compresses the PET bottles inside the heavy-duty chamber.
- The machine repeats the compression cycle until it achieves the required bale density.
- Operators securely tie the compact bale using suitable wire or strapping.
- The operator removes the bale through the side screw, wire rope, or hydraulic pusher arrangement.
This process converts high-volume plastic waste into compact and manageable bales for convenient storage, transportation and recycling.
Technical Specifications of PET Bottle Baling Machine
| Feature | 25 MT (PSB25MT) | 40 MT (PSB40MT) | 60 MT (PSB60MT) | 80 MT (PSB80MT) |
| Feed Opening | 24″ (L) × 34″ (B) | 24″ (L) × 34″ (B) | 30″ (L) × 40″ (B) | 30″ (L) × 40″ (B) |
| Compression Chamber | 24″ × 34″ × 48″ | 24″ × 34″ × 48″ | 30″ × 40″ × 72″ | 30″ × 40″ × 84″ |
| Bale Size | 24″ × 34″ | 24″ × 34″ | 30″ × 40″ | 30″ × 40″ |
| Bale Weight | 60–70 kg | 80–100 kg | 100–250 kg | 100–350 kg |
| Cylinder | 1 No.; 140 mm bore × 70 mm rod × 900 mm stroke | 1 No.; 160 mm × 90 mm × 1200 mm | 1 No.; 180 mm × 100 mm × 1400 mm | 1 No.; 200 mm × 125 mm × 1400 mm |
| Oil Tank Capacity | 60 litres | 150 litres | 200 litres | 250 litres |
| Recommended Hydraulic Oil | Enklo 68 | Enklo 68 | Enklo 68 | Enklo 68 |
| Hydraulic System | Gear pump system | Double pump system | Double vane pump system | Pump system |
| Electric Motor | 5 HP, 1440 RPM | 10.5 HP, 1440 RPM | 10 HP, 1440 RPM | 15.5 HP, 1440 RPM |
All chamber, feed-opening, and bale-size dimensions are specified in inches. We can customize the specifications according to your application requirements.
Operational and Construction Features
Panel or Hand-Lever Operation
The machine can be supplied with panel-operated or hand-lever-operated controls, depending on the customer’s operational requirements.
The straightforward control arrangement enables convenient and dependable machine operation.
Reliable Guiding System
Solid guiding bars support accurate platen movement during compression. Selected configurations are available with two solid-bar guides or side guides for improved operational stability.
Convenient Bale Ejection
Depending on the selected machine configuration, the compressed bale can be removed using:
- Side screw arrangement
- Wire rope mechanism
- Hydraulic pusher system
These bale-ejection options simplify material removal and help reduce manual handling.
Heavy-Duty Safety Construction
The machine is manufactured using heavy plates and strong structural channels. Plate thicknesses of 8 mm and 16 mm, as applicable, provide durability and structural support during high-pressure compression.
Benefits of the PET Bottle Baling Machine
- Reduces the volume of loose PET bottles considerably.
- Produces compact bales weighing up to 350 kg.
- Saves warehouse and storage space.
- Reduces loading and transportation expenses.
- Improves workplace cleanliness and material organisation.
- Supports convenient stacking and handling of PET bales.
- Provides different capacities for varied production requirements.
- Delivers powerful compression through a hydraulic system.
- Offers convenient panel or hand-lever operation.
- Supports organised and profitable plastic recycling.
Choosing the Right Machine Model
PSB25MT
The 25 MT model is suitable for small collection centres and recycling businesses. It produces bales weighing approximately 60–70 kg and operates with a 5 HP motor.
PSB40MT
The 40 MT model is suitable for medium-volume PET waste handling. Its bale weight ranges from 80–100 kg, while the double pump system supports reliable compression.
PSB60MT
The 60 MT model is designed for higher production requirements. It offers a larger compression chamber and produces bales weighing approximately 100–250 kg.
PSB80MT
The 80 MT model is suitable for heavy-duty recycling operations. Its extended chamber, powerful cylinder and 15.5 HP motor can produce bales weighing approximately 100–350 kg.
Applications
The PET Bottle Baling Machine is suitable for:
- Plastic recycling plants
- PET bottle collection centres
- Scrap-processing units
- Beverage manufacturing companies
- Municipal waste-management facilities
- Hotels, shopping malls and commercial complexes
- Warehouses and logistics centres
- Airports and railway stations
- Environmental and community recycling projects
Availability Across Mali
AIM Industries supplies PET Bottle Baling Machines across Bamako, Balandougou, Zégoua, Koutiala, Sikasso, Ségou, Kayes, Mopti, Nioro, Niono, Somasso, Kati, Koro, Bougouni, Baguinéda, Kolondiéba, Kolokani, Pèlèngana, Kouri, Tonka, Kadiolo, Koumantou, Wolossébougou, Gao, Dyero, Kita, Markala, Dialakorodji, Misséni, Massigui, Koulikoro, Sokoura, Dandéresso, San, Fourou, Djidian Kéniéba, Garalo, Kolongo-Bozo, Sanankoroba, Siribala, Kona, Banko, Zinzana, Mpessoba, Macina, Dinangorou, Niamina, Timbuktu, Diabali, Diakon, Kignan, Dogo, Katiéna, Djenné, Moninnpébougou, Barouéli, Ansongo, Lobougoula, Massantola, Niéna, Boro, Dialoubé, Kléla, Konséguéla, Diéma, Banamba, Ségala Mba, Bankass, Didiéni, Dougabougou, Moribabougou, Madina Sako, Diangouté Kamara, Douentza, Sirakorola, Sitakili, Bourem, Mahina, Sibi, Kaboïla, Gourma Rharous, Konobougou, Béma, Falou, Bandiagara, Fatimé, Koumia, Madougou, Fatoma, Ngorkou, Sanando and Ourikela.
Frequently Asked Questions
1. Which PET baling machine models are available?
AIM Industries offers 25 MT, 40 MT, 60 MT and 80 MT models.
2. What is the maximum bale weight?
The 80 MT model can produce bales weighing up to approximately 350 kg.
3. Which hydraulic oil is recommended?
Enklo 68 hydraulic oil is specified for the available machine models.
4. Is hydraulic bale ejection available?
Yes, a hydraulic pusher is available as a bale-ejection option.
5. Can the machine specifications be customised?
Yes, specifications can be customised depending on operational and production requirements.
Choose AIM Industries for PET bottle baling solutions in Mali—save space, reduce costs, and recycle smarter.
